Item | Specification |
Clear-span width | 10m~40m |
Side height | 3m~5m |
Ridge height | 4.6m~11.5m |
Roof pitch | 15°~18°~22° |
Bay distance | 5m |
The longest parts | 5.3m~11.1m |
Roof fixing | bar tensioning |
Main profile | 166x88x3mm~300x120x5.5mm |
Wind loading | 70~100km/h |
Eave connection | Galvanized reinforced steel panel |
Cover material | double PVC-Coated polyester,650g/750g/850g/950g/m², flame retardant, UV resistance, waterproof, comply to DIN 4102 B1, M2 |
